Products
Divimath
HDZero Freestyle VTX
The HDZero Freestyle VTX is a digital HD 720p 60fps 5.8GHZ video transmitter which is compatible with video receivers equipped with HDZero Technology. Thanks to its higher power output capabilities, this VTX is suitable for Freestyle and Long-Range applications. Although the VTX integrates a surge protection circuit, a capacitor with at least capacity of 450µF must be connected parallel to the power supply to smooth unwanted voltage spikes. The VTX is bundled with a BEC that converts 2S-6S to fixed 5.8V with maximum of 5A output current. The VTX also comes with an RHCP antenna which has a U.FL connector.
- Specifications -
Transmitter Power : 25mW, 200mW, 500mW, 1W
Weight : 28g
Dimensions : 40x42x10mm
Mounting Pattern : 30x30 mm with M3 holes
Antenna Interface : Secured U.FL
SmartAudio : Yes
Input Voltage : 7-17V (2S-4S)
Power Consumption : 6-15W
HDZero Race V2 VTX
The HDZero Race V2 VTX is a digital HD 720p 60fps 5.8GHZ video transmitter which is compatible with video receivers equipped with HDZero Technology. Thanks to its compact design and light-weight, this VTX is a perfect match for FPV racers.
- Specifications -
Transmitter Power : 25mW, 200mW
Weight : 6.2g
Dimensions : 34x34x5mm
Mounting Pattern : 20x20mm with M4 to M3 gummies
Antenna Interface : Secured U.FL
SmartAudio : Yes
Input Voltage : 7-26V (2S-6S)
Power Consumption : 5-5.8W
HDZero Whoop VTX
The HDZero Whoop VTX is a digital HD 720p 60fps 5.8GHZ video transmitter which is compatible with video receivers equipped with HDZero Technology. Thanks to its compact design and light-weight, this VTX is a perfect match for whoop and tootpick style FPV drone builds.
- Specifications -
Transmitter Power : 25mW, 200mW
Weight : 5.4g
Dimensions : 32.5x32.5x7mm
Mounting Pattern : 25.5x25.5mm with M2 holes
Antenna Interface : U.FL
SmartAudio : No
Input Voltage : 7-26V (2S-6S)
Power Consumption : 5-5.8W
Happymodel
HDZero Happymodel Mobula7 Whoop
Runcam
HDZero Runcam Micro V2 Camera
HDZero Runcam Micro V2 camera is a 4:3 and 16:9 selectable high definition 720p 60fps camera designed for HDZero Technology supported video transmitters. It supports the camera menu for brightness, contrast, saturation, HV flip, and other camera settings. Thanks to its ultra-high sensitive 1/2 inch sensor, the camera has an excellent low-light performance.
- Specifications -
Aspect Ratio : 4:3 / 16:9 Switchable
Weight : 8.5g
Dimensions : 19x19x21mm
Sensor Size : 1/2 Inch
Luminance : 10650 mV/Lux-sec
FOV : D:155° H:122° V:89° (4:3) , D:145° H:122° V:67° (16:9)
Shutter : Rolling Shutter
Input Voltage : 3.3V
Power Consumption : 0.5W
HDZero Runcam Nano Camera
HDZero Runcam Nano camera is a high definition 720p 60fps camera designed for HDZero Technology supported video transmitters. It supports the camera menu for brightness, contrast,and other camera settings. Thanks to its compact and relatively small design, this camera is a perfect match for tiny builds such as whoop and toothpick style FPV drones. - Specifications -
Aspect Ratio : 16:9
Weight : 4.3g
Dimensions : 14x16x21mm
Sensor Size : 1/2 Inch (!!remark i think this is wrong)
FOV : D:150° H:127° V:69°
Shutter : Rolling Shutter
Input Voltage : 3.3V
Power Consumption : 0.5W
HDZero Runcam Micro V1 Camera (Discontinued)
- Specifications -
Aspect Ratio : 16:9
Weight : 6.5g
Dimensions : 19x19x17mm
FOV : D:160° (!!remark might be wrong)
Shutter : Rolling Shutter
Input Voltage : 3.3V
Runcam Nano HD Camera
Fat Shark
Shark Byte RX5 VRX (Discontinued)
Shark Byte RX5 is a digital HD 720p 60fps video receiver module which is compatible with video transmitters equipped with HDZero Technology. The receiver module has a mini-HDMI port. Thanks to this port, the video receiver can be used with any HDMI display or FPV goggles with HDMI input. The receiver module can be mounted on Fat Shark FPV goggles with the included fan plate but also can be mounted on other goggles with 3rd party 3D printed adaptors.
SB TX5S.1 VTX (Discontinued)
SB TX5M.1 VTX (Discontinued)
SB TX5R.1 VTX (Discontinued)
Scout HD FPV Goggles
Foxeer
Digisight V1 Camera (Discontinued)
Digisight V2 Camera
Digisight V3 Camera
Non-implemented
Foxeer Revo VTX
